*Внешний вид изделия может отличаться от изображения
Фитинг-проушина под дюймовый полый винт
| Code | D1 (mm) | DN | dx (mm) | L1 (mm) | Для полого винта | Дюймы | Размер | Масса, кг |
|---|---|---|---|---|---|---|---|---|
| FT.EYE.G.05.02 | 9,8 | 5 | 3 | 42,5 | R 1/8" | 3/16" | 3 | 0,013 |
| FT.EYE.G.05.06 | 13,2 | 5 | 3 | 43,5 | R 1/4" | 3/16" | 3 | 0,032 |
| FT.EYE.G.06.02 | 10,1 | 6 | 4 | 48,5 | R 1/8" | 1/4" | 4 | 0,018 |
| FT.EYE.G.06.06 | 13,2 | 6 | 4 | 49,5 | R 1/4" | 1/4" | 4 | 0,033 |
| FT.EYE.G.06.10 | 16,7 | 6 | 4 | 52,5 | R 3/8" | 1/4" | 4 | 0,047 |
| FT.EYE.G.08.06 | 13,2 | 8 | 5,5 | 59,5 | R 1/4" | 5/16" | 5 | 0,041 |
| FT.EYE.G.08.10 | 16,7 | 8 | 5,5 | 52,5 | R 3/8" | 5/16" | 5 | 0,046 |
| FT.EYE.G.10.06 | 13,2 | 10 | 7 | 58,5 | R 1/4" | 3/8" | 6 | 0,04 |
| FT.EYE.G.10.10 | 16,7 | 10 | 7 | 54,0 | R 3/8" | 3/8" | 6 | 0,048 |
| FT.EYE.G.10.12 | 21,0 | 10 | 7 | 59,5 | R 1/2" | 3/8" | 6 | 0,094 |
| FT.EYE.G.12.10 | 16,7 | 12 | 9,5 | 58,0 | R 3/8" | 1/2" | 8 | 0,056 |
| FT.EYE.G.12.12 | 21,0 | 12 | 9,5 | 60,5 | R 1/2" | 1/2" | 8 | 0,096 |
| FT.EYE.G.12.16 | 23,0 | 12 | 9,5 | 63,0 | R 5/8" | 1/2" | 8 | 0,111 |
| FT.EYE.G.16.16 | 23,0 | 16 | 12,5 | 67,5 | R 5/8" | 5/8" | 10 | 0,113 |
| FT.EYE.G.16.19 | 26,5 | 16 | 12,5 | 72,0 | R 3/4" | 5/8" | 10 | 0,184 |
| FT.EYE.G.19.19 | 26,5 | 19 | 15 | 78,5 | R 3/4" | 3/4" | 12 | 0,193 |
| FT.EYE.G.19.25 | 33,3 | 19 | 15 | 87,0 | R 1" | 3/4" | 12 | 0,368 |
| FT.EYE.G.25.25 | 33,3 | 25 | 19,5 | 95,0 | R 1" | 1" | 16 | 0,41 |
